Mechanically Expanding Tooling Arbors
|
 |
Standard Tooling Arbor
for bore diameters of 0.75 - 0.875"
Length of tooling is 10.0". Length of collet is
3.25" (one collet)
Journal sizes: 0.7" and 0.4"
p/n R700266.101
1 piece
$1800.00
|
|
|
|
Standard Tooling Arbor
for bore diameters of 0.875 - 1.0"
Length of tooling is 10.0". Length of collet is 3.25" (one collet)
Journal sizes: 0.8" and 0.48"
p/n R700267.101
1 piece
$2000.00
|
|
 |
Standard Tooling Arbor
for bore diameters of 1.0 - 1.25"
Length of tooling is 12.0". Length of collet is 4.0" (two collets)
Journal sizes: 1.0" and 0.56"
p/n R700268.101
1 piece
$2600.00
|
|
|
|
Standard Tooling Arbor
for bore diameters of 1.25 - 1.5"
Length of tooling is 12.0". Length of collet is 4.0" (two collets)
Journal sizes: 1.1" and 0.68"
p/n R700269.101
1 piece
$2800.00
|
|
 |
Standard Tooling Arbor
for bore diameters of 1.5 - 2.0"
Length of tooling is 14.0". Length of collet is 5.0" (two collets)
Journal sizes: 1.3" and 0.78"
p/n R700270.101
1 piece
$3000.00
|
|
 |
Standard Tooling Arbor
for bore diameters of 2.0 - 2.75"
Length of tooling is 16.50". Length of collet is
5.5" (two collets)
Journal sizes: 1.825" and 1.15"
p/n R700271.101
1 piece
$3200.00
|
|
|
|
Standard Tooling Arbor
for bore diameters of 2.75 - 3.75"
Length of tooling is 19.0". Length of collet is
6.0" (two collets)
Journal sizes: 2.55" and 1.70"
p/n R700272.101
1 piece
$3400.00
|
|
 |
Standard Tooling Arbor
for bore diameters of 3.75 - 4.75"
Length of tooling is 19.0". Length of collet is
6.0" (two collets)
Journal sizes: 3.25" and 2.28"
p/n R700273.101
1 piece
$3800.00
|
|
|
|
Standard Tooling Arbor
for bore diameters of 4.75 - 5.5"
Length of tooling is 21.50". Length of collet is
6.0" (two collets)
Journal sizes: 4.375" and 3.500"
p/n R700274.101
1 piece
$4800.00
|
|
|
|
|
|
|
|
|
|
